| 起源の場所 | 中国 |
| ブランド名 | Hightop |
| 証明 | CE，EPA，ISO，TUV |
| モデル番号 | HT25 |
| Specification | Measurement (mm) |
|---|---|
| Total length/Transport length (A) | 2870 |
| Total width (B) | 1400 |
| Upper width (D) | 1320 |
| Total height (top of cab) (C) | 2440 |
| Standard track shoe width (F) | 250 |
| Track gauge (G) | 1150 |
| Minimum ground clearance (H) | 145 |
| Tail turning radius (I) | 700 |
| Track grounding length (J) | 1480 |
| Track length (K) | 1858 |
| Work Quality (KG) | 2150 |
| Bucket capacity (M³) | 0.036 |
| Rated power | 14KW/2200RPM |
| Rotation speed | 12RMP |
| Climbing ability (°) | 40 |
| Maximum excavation height (a) | 3365 |
| Maximum unloading height (b) | 2610 |
| Maximum excavation depth (c) | 2045 |
| Maximum excavation distance (d) | 3430 |
| Minimum turning radius (e) | 1955 |
| Maximum height at minimum turning radius (f) | 2740 |
